Process Basics

The process abstraction

A process is a running program.

Running programs

Diagram - Program: bytes on disk, machine code - Load into memory - Jump to first instruction - Program runs!

Multiprogramming

Problem: we want to run many programs, but we only have one CPU.

What can we do?

There are several solutions. - Batch processing - Add more CPUs - Distributed programming - Virtualize the entire machine - Time sharing (the one we’ll use in this class)

Virtualize the CPU: give programs the illusion of exclusive CPU access

Operating Systems: Three Easy Pieces

Remember how we talked about the kernel idealizes hardware?
One thing modern OSes do is virtualize the CPU.

Many running programs

Diagram - Many virtual CPUs - One physical CPU - Kernel mediates the sharing

Processes “freeze” the state of the CPU

Process control block
- Process ID (unique ID for all running programs)
- Saves register values
- Saves current working directory
- Saves pointer to its memory
- File descriptors
- etc.

Operating Systems: Three Easy Pieces Figure 4.5

https://linux-kernel-labs.github.io/refs/heads/master/lectures/processes.html

UNIX process creation

Copy existing process with fork()

Replace program code with new program with exec()

We will work with process creation syscalls when we get to systems programming.

LPI Figure 24-1

What about the first process?

Single initial process (init)
- Many variations (sysv init rc system, systemd)
- e.g., runs /usr/bin/login program among other things
Running processes form a tree

pstree

Diagram - init process - process tree - process creation

Viewing running processes

ps

View all processes on the system

# all, user-oriented output, include proccesses
# not attached to terminal
ps aux

View the process tree

# include output related to job management, in tree form
ps axjf

Cleaner tree output

# show tree of all processes
pstree

# show tree of only your processes, with arguments
pstree -a $USER

# show tree of your shell's child processes, with arguments
pstree -a $$

Standard I/O

Where does printf’s output go?

int
__printf (const char *format, ...)
{
  va_list arg;
  int done;

  va_start (arg, format);
  done = vfprintf (stdout, format, arg);
  va_end (arg);

  return done;
}

How does your program know where to send it?

glibc-2.4/stdio-common/printf.c

UNIX convention

Every process is given three open files when it runs:

Standard input (stdin)
Standard output (stdout)
Standard error (stderr)

man 3 stdio

“At program startup, three text streams are predefined and need not be opened explicitly: standard input (for reading conventional input), standard output (for writing conventional output), and standard error (for writing diagnostic output).”

On process creation, the parent process’s stdio files are inherited.

Why do this?

Why standard I/O?
Why separate stdout and stderr?

Avoids the need to hardcode I/O decisions or hardware specifics in your program. Instead, I/O decisions are made outside of the program the system user independently of the application.

One reason, I assume, is related to UNIX’s interactive design: running a program from the shell means there is already input and output (the terminal).

Standard I/O is also used for the UNIX philosophy of chaining multiple programs together.

You’ll see this discussed more in tonight’s reading for homework.

Where does `stdin`/`stderr` go?

When running in bash: the terminal itself

echo "hello, world!"

Where does `stdin` come from?

When running in bash: the terminal itself again

cat
# Typing is sent to the cat program's standard in

cat reads a file from stdin and writes it to stdout.

Mark end of input with Ctrl-D

Use Ctrl-D (ASCII EOT character) on an empty line to mark the end of file input

The program is waiting for input from stdin, which is the terminal.

An example with grep

grep "hello"
# Typing is sent to the cat program's standard in

grep reads a file from stdin and writes out lines that contain a given string.

Don’t forget to use Ctrl-D if inputting the stdin file from the command-line.

Waiting for stadnard input is why programs that expect input stop and wait when run from bash.

Running programs

Type the file name of the executable, hit <Enter>.

ls

We’ve already been creating lots of processes from programs such as ls and mkdir.

Find out more about bash syntax.

Command-line arguments

Additional space-delimited strings are arguments passed to the program for processing. They are handled however the program likes, although there are conventions to their format (man 3 getopt).

ls ./ ../

There are special characters bash recognizes that aren’t part of arguments, such as pipes |. We will look at these more when we get to redirection and advanced processes.

There are ways to handle escaping special characters, e.g., \| and including spaces in a single-argument, e.g., with double-quotes.

Where are programs?

UNIX convention: the PATH environment variable

echo $PATH

Why have a PATH?

Finding a programs path

The which program does the lookup for you

which ls

which which

Programs not in the path

hello
# program not found

Why does running hello by itself fail? I compiled it. The program is there.

This is one reason for using the dot path, when we want to specify a path to the file, but do not want to have to type out the absolute path to the current working directory.

./hello

Commands that aren’t programs

which cd
# nothing returned

cd is a builtin command that bash recognizes

How do I find this out? Use type

How do I run a program that I named cd?

How can I check if a command is a program?

The type shell builtin

type cd # builtin

type find # program

type -a echo # both, use -a to see both

If a command is both a program and a builtin, then your shell will default to running the one listed first by type -a.

Quick quiz

How do I run a program that I named cd, assuming it’s in the current directory?

Give the path to the program, e.g.,

./cd

Quick quiz 2

How do I run echo, assuming it’s both on my path and a shell builtin?

You can give the path to the program

/usr/bin/echo Hello, world!

But you can also use the command shell builtin to specify that you would like to run the echo program, not the echo shell builtin. If no echo program exists, then command will default to running the echo shell builtin.

command echo Hello, world!

Redirection

We can use bash to change (redirect) where stdio goes to and comes from.

Benefit of standardizing I/O; control I/O without rewriting the program. No hard-coded files, streams, terminals, etc.

Redirecting stdio to files

File	Suffix
`stdin`	`< infile`
`stdout`	`> outfile`
`stderr`	`2> errfile`

Additional redirection usage

Append

Append to the given file instead of overwriting it.

ls >> filetoappendto

Here documents

Create a file on the fly to pass into stdin.

grep hello << EOT
this is my here document
hello, world!
hello: here document
not included
EOT

Example with `cat`

cat < hello.c

What does cat do?

What does cat < infile do?

How does this differ from running cat infile? - With cat < infile, the shell opens the program and cat runs with an existing program open - With cat infile, the cat program reads the filename and opens the file. - The output is the same in both cases (since the file is the same).

Example with `grep`

grep define < /usr/include/stdio.h

What does grep do?

What does this program do then?

Example of input and output

grep define < /usr/include/stdio.h >result.txt

What does this do?

How can I view grepresults?

Example of error

cat <no_file.txt >cat_error.txt
# The error message is printed to console

Redirecting stderr

cat <no_file.txt >cat_results.txt 2>cat_error.txt
# The error message is saved to cat_error.txt

Redirect stdout/stderr to the same file

cat <no_such_file.txt >cat_error.txt 2>&1

2>&1 means redirect stderr (file 2) to file 1 (stdout). Must place this /after/ the redirect of stdout > grepresults (otherwise it will just use the original stdout.

Another example

# Change hello.c to print to stderr also
vim hello.c
gcc -o hello hello.c
./hello >out.txt 2>err.txt
./hello >out.txt 2>&1
./hello 2>&1 >out.txt

Pipelines

Create complex tools from simple, existing programs.

https://www.gnu.html/software/bash/manual/bash.html#Pipelines

Every program always has input and output whenever it runs
Make each program a well-defined job
Combine programs to create complex tools without having to program from scratch

UNIX philosophy

Make each program do one thing well.
Expect the output of every program to become the input to another, as yet unknown, program.
Design to test early.
Prefer tools over unskilled help.

Full philosophy:

Make each program do one thing well. To do a new job, build afresh rather than complicate old programs by adding new “features”.
Expect the output of every program to become the input to another, as yet unknown, program. Don’t clutter output with extraneous information. Avoid stringently columnar or binary input formats. Don’t insist on interactive input.
Design and build software, even operating systems, to be tried early, ideally within weeks. Don’t hesitate to throw away the clumsy parts and rebuild them.
Use tools in preference to unskilled help to lighten a programming task, even if you have to detour to build the tools and expect to throw some of them out after you’ve finished using them.

From Doug McIlroy

Example: searching for a file

find lists each file in a file tree
grep searches for text

Connecting these programs

# list all files
find > findresults

# get only files with hello in its path
grep hello < findresults

Using process substitution

Not only can we redirect to files, we also redirect to other processes

# grep for files with hello, from find's output
grep hello < <(find)

What about multiples programs?

Use nested substitutions

# find -> grep -> wc
wc < <(grep hello < <(find))

Hard to read… is there a better way?

Using pipes

find | grep hello

find | grep hello | wc

Separate bash commands with a pipe | symbol to pass stdout to stdin

cat /usr/include/stdio.h | grep head

What are pipes?

OS creates two “virtual” files
Writing to first file outputs to second file
Allows processes to pass data between them

Diagram

The operating system handle intermediate files for us. Made possible because all programs have standard in and out.

We’ll use pipes to build our own shell command processor later in the semester.

`xargs` executing a command on many arguments

find | xargs file

xargs takes each line from stdin and turns them into arguments for the given command, in this case the file command.

What does file do?

How can we run file on a lot of things? Use xargs

Building complex tools from simpler ones

Print the first few lines of every header file

find /usr/include | grep "\.h$" | xargs head -n3

head -n3 prints the first 3 lines of a file
xargs takes each line from stdin and executes the given command on it
xargs head -n3 takes each line from stdin and executes head -n3 on it

Complex text processing

I want to get all configuration options defined by the Linux build system.

# search for all configuration options that
# you can choose when building the Linux kernel
find | grep Kconfig | xargs grep "^config"

# deduplicate and sort them as well
find | grep Kconfig | xargs grep -h "^config" | sort | uniq

# trim off the "config " keyword
find | grep Kconfig | xargs grep -h "^config" | sort | uniq \
     | cut -f2 -d' '

# count the results
find | grep Kconfig | xargs grep -h "^config" | sort | uniq \
     | cut -f2 -d' ' | wc -l

Pipe both stdout/stderr

Use |& instead of |

grep define /root |& grep -i Permission

Job management

Managing multipe processes from the shell.

Multiprocessing means we can have multiple programs running concurrently.

Killing jobs

Ctrl-C kills a running program.

Suspending jobs

Ctrl-Z suspends a running program.

find /
# type ctrl-z

[1]+  Stopped                 find /

Resuming a job

fg resumes a suspended program to the foreground.

fg
# find continues running
# type ctrl-z to suspend again

Note: fg is a shell builtin. Use help fg for more info.

Foreground vs. background

Foreground means process is running over the shell
Background means process running separately from the shell

Foreground and background are relative to the interactive shell. The kernel doesn’t distinguish foreground or background processes, all of which are concurrent.

The technical details are more subtle. See man bash JOB CONTROL

Foreground processes

Will block the user from running additional shell commands
Can receive signals, e.g., Ctrl-z

Background processes

No bash signals will work (no Ctrl-C or Ctrl-Z)
Output still to terminal (if not redirected)

Using `bg`

find /
# type ctrl-z
bg
# ctrl-c will not terminate it
fg
# now ctrl-c will work

You won’t be able to see your command-line, because the find command is emitted text so quickly, that the bash shell, which using the same terminal as output, is quickly moved up the screen.

Have faith and type fg then Ctrl-Z to suspend the program.

bg is also a shell builtin.

Using `&`

Suffix the command with & to put it in background immediately.

cat &
# to bring into foreground, use fg
fg
# suspend again with Ctrl-Z
# bring to back again with bg
bg

Warning: the stdout/stderr will still be the terminal if not redirected.

Viewing running jobs

sleep 1m &
cat &
grep hello &
jobs
fg 2 # bring up the second job, cat &

Really killing a process

Ctrl-C basically asks the process to terminate (SIGINT)
SIGINT can be ignored by the program
SIGKILL cannot be

sleep 1m &
ps      # Get PID of sleep
kill -9 # Send SIGKILL to process

See man kill for more details

See man 7 signal for signals and their codes

echo $! will tell the last command’s pid, so we can do this:

sleep 50
ps
kill -9 $!

Quick-and-dirty dev workflow

Use job control to keep an editor running
Don’t exit, just use Ctrl-Z to suspend editor
Compile, test, etc
Use fg to resume editing

vim hello.c     # or emacs hello.c if you prefer emacs
# type Ctrl-Z
gcc -o hello hello.c
./hello
fg

There are better workflows, but this is great for simple, quick scripting tasks for instance.

(Optional) Terminal multiplexing

A terminal multiplexer is like a remote desktop for command-line shells.

We’ll use byobu in this class.

`byobu`

A wrapper for managing terminal multiplexers

byobu is really a wrapper around multiplexers and using tmux by default. GNU screen is an alternative backend for byobu.

Initialization

Setup the multiplexer for bash/emacs/vim’ Ctrl-A keybinding.

byobu-ctrl-a
# Type 2 and hit enter

This is done historically multiplexers use ctrl-a to enter multiplexer commands. We will use F# commands instead.

Entering byobu

In eustis, run

byobu

You can tell you are in byobu (tmux), because there is a status bar at the bottom of the screen.

If you already have byobu sessions, byobu will prompt you to connect to an existing one or allow you to make a new one. Otherwise, byobu will create a new multiplexer session.

Creating additional windows

Press F2 to create a new terminal “window”.

Note the new “tab” with number 1 near the bottom-left of the terminal.

If you can’t see the whole status bar, try expanding the terminal window.

Additionally, you can turn off status notifications interactively with F9. Remember, you will only be able to use keyboard (arrow keys, , ) to navigate.

Detaching and re-attaching

F6 detaches from the byobu session

Rerun byobu to reattach

echo "hello, world!" # to show that we indeed are reattaching
# press `F6` to detach
# you will return to the original eustis bash session.
exit # you can even exit and reconnect
ssh eustis..
byobu
# select (1) or your last byobu session

Navigating byobu

F3 or Alt-<left> to go to the previous window
F4 or Alt-<right> to go to the next window

`byobu` Cheat Sheet

byobu-ctrl-a
# Type 2 and hit enter

Command	Description
`F6`	Detach from byobu
`F2`	New byobu terminal
`F3` or `Alt-<left>`	Go to left terminal
`F4` or `Alt-<right>`	Go to right terminal
`exit` or `Ctrl-D`	exit terminal (not byobu-specific)

Takeaways

Processes

Abstracts away CPU resources
Manages running programs
Creation: duplicate then replace

Standard I/O

stdin, stdout, stderr
Make I/O decisions independent of program

Pipes

Chain multiple programs together, e.g.,

find / | grep bin | wc -l

Manage multiple processes

Suspend and resume processes into the background or foreground to work with multiple programs.

vim hello.c # or emacs hello.c if you prefer emacs
# Ctrl-Z to suspend
gcc -o hello hello.c
./hello
fg # to resume

The process abstraction

Running programs

Multiprogramming

Time sharing

Many running programs

Processes “freeze” the state of the CPU

UNIX process creation

What about the first process?

Viewing running processes

Cleaner tree output

Standard I/O

UNIX convention

Why do this?

Where does stdin/stderr go?

Where does stdin come from?

Mark end of input with Ctrl-D

An example with grep

Running programs

Command-line arguments

Where are programs?

Finding a programs path

Programs not in the path

Commands that aren’t programs

How can I check if a command is a program?

Quick quiz

Quick quiz 2

Redirection

Redirecting stdio to files

Additional redirection usage

Append

Here documents

Example with cat

Example with grep

Example of input and output

Example of error

Redirect stdout/stderr to the same file

Another example

Pipelines

UNIX philosophy

Example: searching for a file

Connecting these programs

Using process substitution

What about multiples programs?

Using pipes

What are pipes?

xargs executing a command on many arguments

Building complex tools from simpler ones

Complex text processing

Pipe both stdout/stderr

Job management

Killing jobs

Suspending jobs

Resuming a job

Foreground vs. background

Foreground processes

Background processes

Using bg

Using &

Viewing running jobs

Really killing a process

Quick-and-dirty dev workflow

(Optional) Terminal multiplexing

byobu

Initialization

Entering byobu

Creating additional windows

Detaching and re-attaching

Navigating byobu

byobu Cheat Sheet

Takeaways

Processes

Standard I/O

Pipes

Manage multiple processes

Where does `stdin`/`stderr` go?

Where does `stdin` come from?

Example with `cat`

Example with `grep`

`xargs` executing a command on many arguments

Using `bg`

Using `&`

`byobu`

`byobu` Cheat Sheet
